JTS 8011D System - Sistema wireless con Microfono Gelato

UR816DV Ricevitore UHF PLL per sistemi wireless a 16 canali selezionalbili

UT-16HWVè progettato con un design tutto in uno. Il trasmettitore è collegato direttamente all'archetto. La fascia leggera e il trasmettitore compatto garantiscono comfort e vestibilità sicura. La capsula cardioide CM-204UL è impiegata per prestazioni di feedback chiare e minime.

Quantità

Descrizione
Dettagli del prodotto

RU-850TH

Frequency Preparation	PLL Synthesized Control
Carrier Frequency Range	470~960MHz
Frequency Setting	REMOSET U(Receive)
RF Outpus	Low / High
Stability	<±10KHz@Fc
Frequency Deviation	±48KHz
Spurious Emissions	<-50dBc
Function	Mute, Auto Power Off, Sensitivity Adjust, Low Battery
Display	LED
Controls	Power, Mute
Battery	UM3, AA x2

RU-8011D

Frequency Preparation

	PLL Synthesized Control
Carrier Frequency Range	470~960 MHz
Frequency Setting	REMOSET U
Receiving Mode	Antenna Diversity
Bandwidth	36MHz
S/N Ratio	>105dB(A)
T.H.D	<0.6%@1KHz
Sensitivity	-95dBm,S/N>80dB
Rejection Ratio	>80 dB
Frequency Response	60Hz~15KHz±2dB
Antenna Type	Fixed Antenna
Antenna Booster Power	None
Display	LCD
Display Contents	Group, Channel, Antenna A/B, Mute Display, AF Meter, RF Meter, Frequency Scan, Audio Level, Volume
Controls	Power ON/OFF, Group, Channel, Mute Display, Frequency Scan (ON/OFF), Key Lock, Volume, Output Attenuation (XLR)
Audio Output Level	Ref/ ±22.5KHz Dev@1KHz Tone ψ6.3 Phone Jack/ -10dBV XLR Jack/ -4dBV(Line) ˴ -24dBV(MIC)
Audio Output Impedance	600Ω
Squelch	Pilot Tone & Noise Mute
Output Connector	1 independent balanced XLR and one Ø6.3mm unbalanced.
Power Supply	DC12~15V/300mA
Dimension (mm)	212.3mm(W)* 38.3mm(H)* 144mm(D)
Notes	Acutal product specifications may vary depending on region
